5.98″ – 16:9 Rugged Handheld Terminal EM-T62

– 5.98″ 16:9 720×1280 IPS Capacitive touch screen
– Android™ 8.1
– USB2.0 OTG
– NXP NFC(13.56M)
– GPS navigation
– Rugged IP65 protection level
– High strength Glass Touch Panel
– MIL-STD-810G, CE, Battery: UN38.3, MSDS, IEC6213

Barcode Scanner

Add-Ons

Product price
Additional options total:
Order total:
Category: SKU: EM-T62

Description

Functions

• Support for Android system
• Integrated 4G all network communication, WiFi, Bluetooth and other communication modes
• Equipped with 5000mAh large capacity battery, the machine has a endurance of 7 hours
• IP65 high protection level, in accordance with MIL-STD-810G
• Support GPS, more accurate positioning
• Equipped with front 2 million and rear 8 million pixel auto focus camera
• Support 1D/2D, NFC and other functional modules to meet the application needs of multiple industries



Product Six Views

Additional information

Application

Delivery, Logistics, Retail, Transportation, Warehouse

GENERAL



CPU

Quad- core ARM® 1.45GHz

CPU Type

MTK Quad-core ARM Cortex-A53

GPU

ARM MaliT720-MP3 450MHz

Operating System

Android 8.1

RAM

2GB LPDDR3

ROM

32GB

Memory expansion

TF max128G

Sensors

E-Compass, Gyroscope, Light Sensor, Range Sensor

Buttons

Power
Volume +/-
HOME Key
Barcode Trigger x2

Notifications

Sound, vibration, LED prompt

Audio

Built-in 8Ω/0.7W Speaker
Mic: Sensitivity:-42db, output resistance 2.2kΩ

Earphones Jack

∮3.5mm

Dimentions

185mm x 93mm x 20.7mm

Weight (with battery)

380g

CAMERA



Rear Camera

8.0MP

Front Camera

2.0MP

Focus mode

Autofocus

Rear Flash

Single color LED flash

DISPLAY



Brightness

430 Nits

Screen Size

5.98"

Resolution

IPS 720×1280

Touch Panel

5 points Capacitive, G+FF, Rigidity: above 7H-Anti-scratch

POWER



Battery Capacity

Li-Po 5000mAh / 3.7V

Charging

AC100V ~ 240V、50Hz/60Hz output DC 5V/2A
Pogo Pins

Interface

Micro USB 2.0, OTG

CONNECTIVITY



WWAN

CMCC 5M:
LTE 1/2/3/4/5/7/17/20/38/39/40/41
WCDMA 1/2/5/8
TD-SCDMA 34/39
GSM 2/3/5/8

Bluetooth

BT4.0 BLE

WLAN

WiFi 802.11 a/b/g/n 2.4G 5G

GPS

GPS; Capture sensitivity::-160 dBm;Cool Start Time:<60 seconds,Hot start time:<28seconds,frequency::0.25 Hz … 10 MHz (configurable)

NFC

* ISO/IEC 14443A, ISO/IEC 14443B PCD 106 kbit/s to 848 kbit/s
* ISO/IEC 14443A, ISO/IEC 14443B PICC 106 kbit/s to 424 kbit/s
* MIFARE reader encryption mechanism (MIFARE 1K/4K)
* Reading NFC Forum tags (MIFARE Ultralight, Jewel, FeliCa open tag, ISO/IEC 14443-4)
* Reading DESFire card
* ISO/IEC 15693/ICODE reader
* NFC-IP1 and NFC-IP2 protocols (ISO/IEC 18092 /ECMA 340 and ISO/IEC 21481/ECMA 352) 106 kbit/s to 424 kbit/s
* B’ and MIFARE card emulation

DURABILITY



Working Temperature

-10°C to 50°C

Storage temperature

-20 °C to 60 °C

Humidity

5%-95% (Non-Condensing)

Ingress protection

IP65

Drop test (Operating)

1.2m composite wood floors

Certifications

CE, NB, MIL-STD-810G, UN38.3, MSDS, IEC62133
